￭ Surface treatment: Electrolytic plating or Powder painted ( Optional )
￭ Built-in 30X camera module plus additional dual camera housings
￭ Adopt Oriental's motor
￭ Built-in micro switch to protect vertical rotation
￭ Support home position function
￭ Meet IP66
￭ Rotating Speed: Pan:100°/s; Tilt:100°/s
￭ Rotating Angle: Pan: 0°~360° continuous, Tilt: +90°~ -90°
￭ Input Voltage : 24VDC
￭ Interface: IP ( RJ45 )
￭ Protocol: Pelco-D, Pelco-P
￭ Dimension: 690 mm ( W ) x 450 mm ( H )
￭ Customized camera & Lens combination
￭ Application: Highly corrosive or moisture environments, valuable facility protection such as
chemical plants, power system, forest protection, airport guard, coastal guard, ship,.. etc.
￭ Certificate: Ex db IIC T6 / Ex tb IIIC T85° C ( pending )
|
