￭ Finish treatment: Electrolytic plating or Powder painting ( optional )
￭ Double-layer stainless steel structure. Internal compartment is filled with water to achieve the
effect of heat insulation and cooling
￭ There are two holes located in upper and lower position for water circulation to cool down the
temperature
￭ Front window blowing design can reduce the glass and internal temperature and clean the dust
￭ Meet IP 68
￭ External Interface: 1/2" or 3/4" gland screw hole according to actual requirement
￭ External screws are made of stainless steel
￭ Front window use 10mm thickness tempered glass
￭ Environmental temperature:-10°C~ 100°C
￭ Dimension: 310mm (L) x 142mm (W) x 142mm (H)
￭ Customized camera & Lens combination
￭ Application: Hazardous area, highly corrosive environments or more dangerous environments,
such as arsenals, chemical plants, oil, gas refineries, coal mining, etc.
￭ Certificate: Ex d IIC T6 Gb / Ex tb IIIC T85℃ Db
￭ Optional accessory: YK-0336-22 Stainlees Steel Bracket, Bracket dimension:
350mm ( L ) x 124mm ( W ) x 100mm ( H )
|
Type
|
Description
|
Download
|
| Spec | Specification Sheet |  |
| Manual | User Manual | |
